Getting 503 error in VS CODE when starting the MCP services for starting MCP server,
Imaging and all other MCP services are up and running fine.
Explanation
In the MCP Server log
Caused by ProxyError ‘Unable to connect to proxy’ is seen
This issue is related to the proxy settings (system-level proxy variables) configured on the server. After disabling the proxy configuration, user was able to successfully connect to the MCP Server.
If proxy access is required, it is recommended to keep the proxy settings after configuring a NO_PROXY entry for the Imaging host/IP.
NB: The default log path is: \ProgramFiles\CAST\Imaging-MCP-Server\logs
Default installation path is: \ProgramData\CAST\Imaging-MCP-Server\setup-config
Resources
Getting started with CAST Imaging MCP Server
CAST Imaging v3 Product Documentation
CAST Imaging Troubleshooting Guides
Additional Resources
CAST Highlight Product Documentation
CAST Highlight Troubleshooting Guides
Ticket
56749
